Transparent screen series

产品概述产品参数

Transparent screen series

Concave and convex bending

A single box can achieve simultaneous concave and convex bending.

Extremely thin and otherworldly

A single box weighs 7kg and is only 94.5mm thick.
Arc function

Support any adjustment and splicing of internal and external arcs, the maximum Angle of the whole box is ±30°.
Cylindrical splicing

12 boxes can achieve cylindrical splicing, with a diameter of about 1.9 meters.
Wavy function

Angle support ± 30°, ± 25°, ± 20°, ± 15°, ± 10°, ±5°, 0°.

High definition
Super protection
Super light and thin
High Refresh
Convenient maintenance
170° ultra wide viewing Angle

Product parameter

Product model	Horizontal and vertical spacing (mm)	Box size (mm)	Refresh rate (Hz)
DLX2.5-5.0G	2.5-5	1000x500x32	3840
DLX3.91-7.82G	3.9-7.82	1000x500x32	3840
DLX6.25-12.5G	6.25-12.5	1000x500x88	3840
DLX7.81-12.5G	7.81-12.5	1000x500x88	3840
DLX8.33-12.5G	8.33-12.5	1000x500x88	3840
DLX8.33-16.67G	8.33-16.67	1000x1000x81	3840
DLX10.416-10.416G	10.416-10.416	1000x500x32	3840
DLX10.41-12.5G	10.41-12.5	1000x500x88	3840
DLX12.5-12.5G	12.5-12.5	1000x500x88	3840
DLX12.5-25G	12.5-25	1000x500x86	3840
DLX15.625-15.625G	15.625-15.625	1000x500x32	3840
DLX15.625-25G	15.625-25	1000x1000x86	3840
DLX15.625- 31.25G	15.625-31.25	1000x500x86	3840
DLX16.67-16.67G	16.67-16.67	1000x1000x81	3840
DLX33.33-16.67G	33.33-16.67	1000x1000x86	3840
DLX20-20G	20-20	1000x1000x88	3840
DLX25-25G	25-25	1000x1000x86	3840
DLX31.25-31.25G	31.25-31.25	3000-15000可调3	3840

产品型号

DLX-TBFN-16H2.5

DLX4FI

DLX2.5-5.0G

DLX4DI

色温K

2.5

3000-15000可调3

2.5-5

3000-15000可调
水平视角(°)

1602

1603

SMD1415/1515

160
垂直视角(°)

1402

1403

条宽20.5mm

140
发光点中心距偏差

<3%

<3%

1000x500x32

<3%
亮度均匀性

≥97%

≥97%

7.5

≥97%
对比度

5000:1

5000:1

IP 31

5000:1
换帧频率(Hz)

50/60

50/60

160

50/60
刷新率(Hz)

1920/3840(可选)

1920/3840(可选)

160

1920/3840(可选)
